Outdoor three-phase automatic adjustment power compensation regulator
- Category：SBW-F split-regulation compensation regulator
- Product overview of split-regulated power regulators SBW-F series three-phase split-adjustment fully automatic compensating power voltage stabilizer is an improved voltage stabilizer of SBW series products. It is suitable for grids with unbalanced
- Hotline：
Product overview of split-regulated power regulators
SBW-F series three-phase split-adjustment fully automatic compensating power voltage stabilizer is an improved voltage stabilizer of SBW series products. It is suitable for grids with unbalanced three-phase voltage input. When the grid fluctuates or load current and voltage, three-phase output It can automatically balance and maintain the advantages of stable voltage regulation.
Application occasions of split-regulation power stabilizer
It is widely used in post and telecommunications, shopping malls, elevators, hospitals, printing, securities and other occasions where normal voltage is required, as well as workshops of large and medium-sized industrial and mining enterprises, part of the power supply and important equipment and stand-alone supporting.
Product performance of split power regulator
| Input voltage |
Three-phase four-wire system, phase voltage 220±20%, line voltage 380V±20% or phase voltage 220V±30%, line voltage 380V±30% (please specify when ordering) |
| The output voltage | Three-phase phase voltage line voltage 380V |
| Output accuracy | 2-5% frequency: 50HZ/60HZ |
| efficient | ≥95% (power level above 50KVA) |
| responding speed | ≤1.5S (when the external voltage changes 10%) |
| Ambient temperature | -5℃—+40℃> |
| Insulation resistance | ≥1MΩ |
| Electric strength | Power frequency sinusoidal voltage 200V for 1 minute without breakdown or flashover |
| Overload capacity | Double the rated current for 1 minute |
| Waveform distortion | No additional waveform distortion |
| Protective function | Overvoltage, overcurrent, phase loss, phase sequence protection and mechanical failure protection |
Model specification
| Phase |
Model specification (KVA) |
Rated capacity (KVA) |
Maximum output current (A) |
Dimensions (mm) (D×W×H) |
Number of cabinets |
Weight (kg) |
| Three-phase | SBW-F-20 | 20 | 30 | 680×1100×1320 | Single cabinet | 480 |
| SBW-F-30 | 30 | 45 | 680×1100×1320 | 500 | ||
| SBW-F-50 | 50 | 76 | 680×1100×1320 | 652 | ||
| SBW-F-100 | 100 | 152 | 800×1100×1420 | 847 | ||
| SBW-F-150 | 150 | 227 | 1000×1350×1650 | 1360 | ||
| SBW-F-180 | 180 | 273 | 1000×1350×1650 | 1380 | ||
| SBW-F-200 | 200 | 303 | 1000×1350×1650 | 1410 | ||
| SBW-F-225 | 225 | 341 | 1000×1350×1650 | 1470 | ||
| SBW-F-250 | 250 | 379 | 1000×1350×1650 | 1490 | ||
| SBW-F-300 | 300 | 455 | 1000×1350×1650 | 1700 | ||
| SBW-F-400 | 400 | 606 | 1000×1350×1650 | 1760 |
| Phase |
Model specification (KVA) |
Rated capacity (KVA) |
Output current |
Dimensions (mm) (D×W×H) |
Number of cabinets |
Weight (kg) |
| Simplex | DBW-10 | 10 | 45 | 500×650×1320 | Simplex | 270 |
| DBW-15 | 15 | 68 | 500×650×1320 | 275 | ||
| DBW-20 | 20 | 91 | 500×650×1320 | 283 | ||
| DBW-25 | 25 | 114 | 500×650×1320 | 300 | ||
| DBW-30 | 30 | 136 | 500×650×1320 | 310 | ||
| DBW-40 | 40 | 182 | 500×700×1500 | 330 | ||
| DBW-50 | 50 | 227 | 620×800×1500 | 360 | ||
| DBW-60 | 60 | 273 | 620×800×1500 | 365 | ||
| DBW-80 | 80 | 364 | 680×920×1620 | 480 | ||
| DBW-100 | 100 | 455 | 680×920×1620 | 490 | ||
| DBW-120 | 120 | 545 | 680×920×1620 | 496 | ||
| DBW-150 | 150 | 682 | 680×920×1750 | 530 | ||
| DBW-180 | 180 | 818 | 680×920×1750 | 540 | ||
| DBW-200 | 200 | 909 | 680×920×1750 | 550 | ||
| Three-phase | SBW-20 | 20 | 30 | 570×700×1210 | 289 | |
| SBW-30 | 30 | 45 | 570×700×1210 | 300 | ||
| SBW-50 | 50 | 76 | 570×700×1210 | 315 | ||
| SBW-60 | 60 | 91 | 570×700×1210 | 320 | ||
| SBW-80 | 80 | 121 | 620×800×1210 | 460 | ||
| SBW-100 | 100 | 152 | 620×800×1210 | 480 | ||
| SBW-120 | 120 | 182 | 620×800×1210 | 482 | ||
| SBW-150 | 150 | 227 | 680×920×1620 | 650 | ||
| SBW-180 | 180 | 273 | 680×920×1620 | 673 | ||
| SBW-200 | 200 | 303 | 680×920×1620 | 680 | ||
| SBW-225 | 225 | 341 | 800×1000×1750 | 810 | ||
| SBW-250 | 250 | 379 | 800×1000×1750 | 830 | ||
| SBW-300 | 300 | 455 | 900×1100×1860 | 1040 | ||
| SBW-320 | 320 | 485 | 900×1100×1860 | 1052 | ||
| SBW-350 | 350 | 630 | 900×1100×1860 | 1080 | ||
| SBW-400 | 400 | 606 | 900×1100×1860 | 1106 | ||
| SBW-450 | 450 | 681 | 900×1100×1860 | 1113 |
★Please use this product in accordance with normal conditions of use.
★For places where the three-phase power grid is particularly unbalanced (refer to the voltage deviation of A, B, C three-phase voltage more than 10%), in order to ensure the output voltage regulation accuracy of the voltage stabilizer, please choose the SBW-F series voltage stabilizer.
★For special use places such as coal mines and tunnels, there are factors such as long lines and large pressure drops. When ordering, please provide information about the wire length, the cross-sectional area of the civil line, the capacity of the power supply transformer, and the maximum load current of the place of use. Expected voltage stabilization effect.
