Ultra-low voltage regulator for household appliances
- Category:TNS SVC high precision automatic voltage stabilizer
- product description SVC-E (digital display) series single-phase voltage stabilizer adopts digital display technology, which can automatically display output current, output voltage, protection status, etc., with delay protection, over-voltage and u
- Hotline:
product description
SVC-E (digital display) series single-phase voltage stabilizer adopts digital display technology, which can automatically display output current, output voltage, protection status, etc., with delay protection, over-voltage and under-voltage protection, automatic alarm all-round protection, etc. Excellent features. (Note: 2KVA and above products only have the protection of delay, overvoltage, undervoltage, etc., and have the function of mains direct connection)
Use occasion
This regulator is mainly used in household appliances, air conditioners, refrigerators, TVs, induction cookers, water heaters, chargers, lighting and other electrical equipment.
The main technical parameters
Input voltage | Single-phase 140-250V | ambient temperature | -10℃-+40℃ |
The output voltage |
0.5KV-5KVA single-phase 220V and 110V 8KVA-30KVA single-phase 220V |
relative temperature | <95% |
Voltage regulation accuracy | 220V±3% and 110V±6% | temperature rise | <60 |
frequency | 50Hz/60Hz | waveform distortion | No additional waveform distortion |
Adjust the time | <1 second (when the input voltage changes by 10%) | load power factor | 0.8 |
efficient | 90% | Dielectric strength | 1500V/min |
Overvoltage protection | 246V±4V | Insulation resistance | >5MΩ |
delay time | Long 5 minutes ± 2 minutes Short 5 seconds ± 2 seconds |
Model Specifications
Model Specifications (KVA) | Product size (D×W×H)(mm) | Packaging(D×W×H)(mm) | Taiwanese |
SVC-E0.5 | 170×190×130 | 415×245×340 | 4 |
SVC-E1 | 200×220×160 | 495×285×385 | 4 |
SVC-E1.5 | 200×220×160 | 495×285×385 | 4 |
SVC-E2 | 270×220×210 | 530×340×290 | 2 |
SVC-E3 | 300×220×230 | 550×365×315 | 2 |
SVC-E5 | 340×260×240 | 660×425×330 | 2 |
SVC-E8 | 340×340×210 | 400×400×265 | 1 |
SVC-E10 | 340×340×210 | 400×400×265 | 1 |
SVC-E15 | 360×340×670 | 420×400×700 | 1 |
SVC-E20 | 360×340×670 | 420×400×700 | 1 |
SVC-E30 | 460×400×690 | 520×460×720 | 1 |
